Bullet Design Catalog

Click on any design to view more details.


This expanding catalog contains designs that are already on file. As new designs are ordered, they are numbered and added here. You may choose from these designs, use one of these as a basis and specify modifications, or submit a completely custom drawing either electronically or by regular mail.

These molds are designed to fit RCBS and six cavity Lee handles. Ordered body diameter tolerance is (+0.002/-0.000).

Mass produced bullet molds are designed with very conservative, minimal dimensions north of the crimp groove, so that they will chamber in the great variety of firearms out there. Best accuracy is usually accomplished with a much closer fit, tailored to a particular firearm. This catalog is a record of molds I've made, and posted for reference. Be aware that due to their custom nature, many of these bullets are designed for a specific purpose or firearm, and won't necessarily fit or feed as drawn in all guns of that caliber.


Jump to page:  1 2 3 4 5 6 7 8 9 10 11 12 13 14 View All

31-170BG

Gas check

31-170C

30-30 Gas check

31-170E

30-30 Gas check

31-170F

Gas check RD design

31-170FT

Gas check

31-170G

Inspired by Lyman 311291

31-170H

308 / 7.62 X 51

31-170JG

Inspired by 311041

31-170L

308403 / 311403 clone

31-170SG

Gas check

31-170SL

Gas check RD design

31-170T

308 Win

31-170U

30-30 T/C Contender

31-175A

Gas check

31-175B

Tapered design

31-175R

Gas check

31-177BG

SAAMI spec 300 AAC nose. OAL .5" less than block length.

31-180A

Gas check

31-180EG

Gas check

31-180S

Gas check

31-185KG

Gas check

31-185S

K31 7.5 X 55 Swiss .297 bore

31-190G

Gas check

31-190S

303 Savage

31-195B

Tapered design

31-195RG

Gas check

31-200B

7.62 x 39 Gas check

31-200C

7.62 x 39

31-200G

Gas check

31-200H

Tapered design

31-200J

303 Gas check

31-200K

Gas check Tapered design

31-200L

Inspired by 314299 Gas check

31-200NR

308 Win Bore engraving ring

31-200R

7.62 X 54R Gas check

31-200S

Tapered design

31-200T

7.62 x 39

31-200TG

7.62 x 39 Gas check

31-210BG

Gas check

31-210FG

Gas check

31-210NR

Has nose engraving ring

31-215E

300 Blackout Powder Coat

31-215LG

Inspired by Lyman 311284 Gas check

31-216T

Gas check

31-220BG

Lee Enfield

31-220E

Gas check

31-230E

30 BR Egan Gas check

31-230F

Gas check

31-230G

Tapered design

31-235AG

Gas check

31-235M

Long tapered bore ride

31-240B

Gas check

31-240D

Double crimp groove for Blackout and 308

31-240E

Double crimp groove for Blackout and 308

31-240EG

Gas check

31-245BG

Gas check

31-245BT

Tumble lube

31-250E

Blackout Powder Coat

31-255J

Tapered bore ride

31-260B

Gas check

31-260J

Tapered bore ride

31-9000

Basis for hollow base nose pour. Pin must be outsourced.

32-093C

Heeled design

32-1100

Basis for hollow base nose pour. Pin must be outsourced.

32-125LG

Gas check

32-135G

Gas check

32-155L

Inspired by Lyman 321317

32-160G

32 Win Spl
